Description
Description:
It'll prove to be fast, smart and reliable.
This is an integrated LTE 4G/3G (Category 4) modem, with speeds up to 150Mbps downstream and 50Mbps upstream. It is compatible with EE, Vodafone, O2 and Three mobile networks and any MVNOs on those networks.
This router offers constant connectivity with Dual SIM LTE. It is ideal for primary and backup mobile broadband connections. It will automatically switches to the backup SIM if the main SIM's connection drops or experiences significant delays.
The V2620-LN offers versatile Multi WAN failover. Connect the Vigor 2620 to 4G mobile broadband, ADSL2+, VDSL2 or Ethernet. If the primary connection fails, the router automatically resumes connectivity with its failover connections.
This is a VDSL2 & ADSL2+ modem. Connect it to Fibre to the Cabinet (FTTC) VDSL2 or ADSL, with support for VDSL2 Vectoring. Openreach MCT approved and SIN498 compliant.
This router delivers virtual private networking. Create a secure LAN to LAN VPN tunnel for your remote office to the main office. Supports Ipsec IKEv1, IKEv2, DrayTek SSL Tunnel and L2TP with Ipsec. Dial in to the Vigor 2620Ln's network with DrayTek SSL VPN. Ans it is designed for centralised management. Configure and manage the Vigor 2620Ln remotely through the VigorACS central management platform.
Features:
- LTE 4G/3G Modem - up to 150Mbps
- Constant connectivity with Dual SIM LTE safeguards against mobile network outages
- Versatile Multi WAN failover ensure high availability
- Gigabit LAN Ports and VLANs allows separate private and guest networks and makes full use of LTE 4G bandwidth
- VDSL2 & ADSL2+ modem, compatible with all ISPs in the UK and Ireland
- Virtual Private Networking with Securely encrypted network access
- Easily manage the Vigor 2620LN and its SIMs remotely
- Designed for Centralised Management, which saves time and money
Specifications:
| LAN Ports (Switch) | 2 x Gigabit Ethernet (1000Mb/s) Ports (P2 switchable to WAN2 port) |
| WAN Ports (One as Primary, Others as Failover) | WAN1 : ADSL/VDSL - RJ-11 WAN2 : Gigabit Ethernet - RJ-45 LTE : 3G/4G/LTE modem - dual SIM slot 2 x Removable LTE wireless antennas Wireless On / Off / WPS button Recessed factory reset button |
| Performance | Firewall: Up to 300Mbps NAT Sessions: 30,000 Wireless LAN: Up to 300Mbps (2 Spatial Streams @ 40MHz) IPSec VPN: Up to 50Mbps (using AES 256-bit encryption) SSL VPN: Up to 25Mbps |
| 4G LTE Modem Features | Dual SIM LTE Category 4 Unlocked to any network (BT, EE, 3, O2, Vodafone, Eircom) LTE FDD Supported Frequency Bands: 1, 3, 7, 8, 20 Max Data Rates: 150Mbps Downlink, 50Mbps Uplink, 2 standard size SIM Slots (primary and backup) Removable SIM slot cover 2 Removable LTE wireless antennas (SMA connector fitting) SMS Inbox - send and receive SMS text messages SMS Router Commands - Status Report, Reboot via text message |
| Wireless LAN Features | 2.4GHz - 802.11b/g/n Wireless Wireless LAN On/Off button 2 Internal Wireless Antennas Up to 4 SSIDs Whitelist / Blacklist individual wireless clients per SSID (by MAC address) Time Scheduling for Wireless radio and/or individual SSIDs Active Client list in Web Interface Station Control, limit wireless client access time per day Wireless Rate-Control Wireless Client Isolation per SSID WPA/WPA2 Encryption Access Point Discovery WDS (Wireless Distribution system) for WLAN Bridging and Repeating WMM (Wi Fi Multimedia) support |
| Firewall and NAT Features | 40 Port Redirection rules 40 Open Port rules (10 port ranges per rule) DMZ Host Configurable SIP (VoIP) and RTSP Application Layer Gateway (ALG) services Policy Based Firewall MAC Address Filter SPI ( Stateful Packet Inspection ) with FlowTrack Mechanism DoS / DDoS Protection• IP Address Anti spoofing E-Mail Alert and Logging via Syslog Bind IP to MAC Address Object based Firewall to apply rules to Objects / Groups as well as subnet/network addresses |
| ADSL Standards | ANSI T1.413 Issue 2 ITU-T G.992.1 G.dmt (ADSL) ITU-T G.992.2 G.lite ITU-T G.992.3 ADSL2 ITU-T G.992.5 ADSL2+ Annex L (READSL) Annex A Annex M ANFP Issue 3 compliant/certified (for Annex A and Annex M) DSL Forum : TR-048/67 and TR-100 |
| VDSL Standards | ITU-T VDSL2 G.993.2• ITU-T G.993.1, G.997.1 Band Plan: G.998, G.997 Annex A, Annex B, Annex C VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a OLR, UPBO, DPBO Supported US0 Supported Loop Diagnostic Mode DSL Forum WT-114 |
| Router Management | Web based User Interface (HTTP / HTTPS) CLI ( Command Line Interface ) via Web Console, Telnet or SSH Administration Access Control SMS Alert Service Brute Force protection Configuration backup / restore Built in diagnostic function (ping, traceroute) Firmware Upgrade via Web Interface, TFTP, VigorACS Logging via Syslog TR-069 TR-104 Access Point Management: Centrally Manage 2 DrayTek VigorAP wireless access points |
| Quality of Service (QoS) | Guaranteed bandwidth for VoIP Class based bandwidth Layer 2 and 3 (802.1p and TOS/DCSP) DiffServ Code Point classifying 4 level priority for each direction (inbound / outbound) Bandwidth borrowing |
| Power | Requirement: 220 to 240VAC Operating: DC 12V 1A (via external PSU, supplied) Consumption: 12W max |
| Temperature | Operating: 0°C / 32°F to 45°C / 113°F Storage: -25°C / -13°F to 70°C / 158°F |
| Dimensions | Height: 39mm / 1.54" Width: 131mm / 5.2" Length: 207mm / 8.15" |
| Weight | Without antenna: 440g / 0.97lb |
| Mounting | Wall mountable |
User guides
Download User Guides:
Data Sheet
DrayTek Data Book
Quick Start Guide
User Guide
